Product Detail

Design Concept



Created for musicians who pursue tonal perfection, this Reamp box empowers you to rediscover and refine the tones that truly stay in your mind. Its intuitive operation allows you to easily select between active and passive modes based on your setup. With just a twist of the Level and Gain controls, your recorded D.I.track can be seamlessly fed into your tone chain-without loss or color.

The dual-transformer architecture brings out richer harmonic content, making this unit an indispensable tool in your reamping and tone-shaping workflow.





Features





Dual-mode Reamping for different musical styles and tonal demands



Dual-channel signal processing



Passive mode delivers warm tone with musical harmonics at a reasonable signal level



Active mode provides up to +16dB of full-frequency gain



Three ground lift options to suit various grounding environments



Internally isolated power supply in active mode



Dedicated Buffering signal in active mode



Wide voltage input range: accepts 9V to 18V DC, center-negative







Specifications



Frequency Response:20Hz ~ 20kHz (+/-1.05dB)
Dynamic Range:   Passive: 140dB   Active: 125dB
Total Harmonic Distortion: Passive: 0.002%@ 1kHz/0dBu
Active: 0.005%@ 1kHz/0dBu input
Noise Floor:-117dB
Max Input Level:Passive: +26dBu    Active: +22dBu
Phase Deviation:0°@800Hz
